Engineered & Made In Germany

Harmonic Design products are designed, developed and hand-crafted in South Germany, Steinheim an der Murr.

Over 38 Years Of Experience

Since its foundation in 1980, Harmonic Design stands for research, development and manufacturing of cutting edge loudspeaker systems and acoustic service

Link to Harmonic Design web site

CATALOGUE

Download the complete PDF catalogue

HLS20/P

Hybrid Line Source

  • passive 2-Way loudspeaker
  • 2 x10″ LF neodym + 3 x 1.4″ neodym HF
  • coverage 100° x 40°
  • innovative hybrid horn, bassreflex, coaxial enclosure design
  • extreme SPL up to 143dB

HLS24/P

Hybrid Line Source

  • passive 2-Way loudspeaker
  • 2 x12″ LF neodym + 4 x 1.4″ neodym HF
  • coverage 100° x 40°
  • innovative hybrid horn, bassreflex, coaxial enclosure design
  • extreme SPL up to 144dB

LAS Series

Line Source Array

  • passive 2-Way 1 x 12″ +2 x 14″ N
  • 90º x 15º or 120º x 15º coverage
  • coverage 100° x 40°
  • compact enclosure design
  • SPL 136dB
  • cylindrical wave propagation

hd 181

Universal Speakers

  • passive 2-Way
  • 1×8″ + 1″ horn
  • coverage 80° x 60°
  • precise & even coverage
  • 250watt
  • SPL max 121dB

hd 281M

Monitor Speaker

New model due late 2019
  • passive 2-Way
  • 2×8″ + 1″ elliptical horn
  • coverage 80° x 60°
  • 500watt
  • SPL max 124dB

hd 8CXN

Universal Speakers

New series 8″ and 6″ coming May 2019
  • passive 2-Way coaxial
  • 1×8″ + 1″ horn
  • coverage 80° x 70°
  • 250watt
  • SPL max 125dB

hd MP10N

Multipurpose Speakers

  • passive 2-Way
  • 1x 10”  + 1.4″
  • coverage 80° x 80°, 90° x 60°, 60° x 40°
  • monitor angle 32°/35° and 45°
  • 600watt
  • SPL max 134dB

hd MP12N

Multipurpose Speakers

  • passive 2-Way
  • 1x 12” + 1.4″
  • coverage 80° x 80°, 90° x 60°, 60° x 40°
  • monitor angle 32°/35° and 45°
  • 600watt
  • SPL max 134dB

hd MP15N

Multipurpose Speakers

  • passive 2-Way
  • 1x 15” + 1.4″
  • coverage 90° x 60°or 60° x 40° horn
  • monitor angle 32°/35° and 45°
  • 600watt
  • SPL max 135dB Sens 101dB
hd Sub12
hd Sub15
hs Sub18

hd Sub 12, 15, 18

Subwooffers

  • P12 400w SPL max 120dB
  • P15 1000w SPL max 136dB
  • P18 1800w SPL max 141dB
hd P12stereo
hd P15
hd P18
P12 module
P15/18 module

hd P12, P15, P18

Active Subwoofers

  • P12 3 x 500w SPL max 120dB
  • P15 1 x 2500w 2 x 800w SPL max 135dB
  • P18 1 x 2500w 2 x 800w SPL max 137dB
  • DSP via hd Level Z software

hd Infra218

Hybrid Subwoofer

  • 2 x18″ Hybrid Subwoofer
  • 3600W rms 14400W peak
  • frequency response from 28hz
  • sensitivity 106bB at 1W11m, SPL max 149dB

ML hd Beamforming Series

Active Beamforming Columns

  • 2″ drivers
  • 8, 16, 24 or 32 drivers
  • 75 watt + DSP amp module per driver
  • Vertical Steering & Opening angle
  • up to 4 beams
  • Cardioid add on

PL hd Beamforming Series

Active Beamforming Columns

  • 3″ drivers
  • 8, 16, 24 or 32 drivers
  • 75 watt + DSP amp module per driver
  • Vertical Steering & Opening angle
  • up to 4 beams
  • Cardioid add on

hd C Series

Commercial Columns

  • Point Source coverage pattern
  • 2″ drivers
  • 2, 4, or 8 drivers
  • 1 way passive
  • coverage 100° x 50°, 40°, 30°
  • 100 – 200 watt (100 volt option )

hd ML Series

Passive Columns

  • Line Source coverage pattern
  • 2″ models
  • 12, 16, 24 or 32 drivers
  • 1 way passive
  • coverage ML 100° x 15°, PL 80° x 10°
  • 400 – 800 watt

hd PL Series

Passive Columns

  • Line Source coverage pattern
  • 3″ models
  • 12, 16, 24 or 32 drivers
  • 1 way passive
  • coverage ML 100° x 15°, PL 80° x 10°
  • 400 – 800 watt

hd CX Series

Commercial Columns

  • Point Source coverage pattern
  • 3.5″ drivers + Coaxial 1″
  • 1, 3, 5 or 7 drivers
  • 1 way passive
  • coverage 80° x 80°
  • 40 – 265 watt (100 volt option )

hd Slim265

Subwoofer

  • 2 x 6″ drivers
  • 300w SPL max 118dB
  • 55hz – 200hz
  • Sensitivity 98dB (1w/1m)
  • 4Ω or 16Ω

hd Qi Series

DSP Amplifiers

  • Qi5002 & Qi5004 4in / 4out
  • QI50002 2 x 500w + 2 x DSP out
  • QI50004 4 x 500w
  • MultiDSP module
  • Remote software hd LevelZ

hd LevelZ

Remote Software

  • Software for Qi Amps & P Series Subs

Difference between POINT Source and LINE Source its important to understand our different models
